Borg Warner Turbos S480sx4 Turbocharger (960+HP)

The Borg Warner S480sx4 is commonly used as the atmosphere (big/top turbo) in compound turbo set-ups (although it can be used as a single). The Borg Warner S480 turbo flows up to 120lbs/min, enough flow for a maximum of 960 HP! This Borg Warner turbo has been and still is a popular application for compound set-ups where it is compounded in conjunction with the stock turbo or an aftermarket one. Whether you want to finish the quarter mile in record time, make a full pull with a sled, or dominate the dyno, this turbo will help get you there.

Borg Warner S480 Turbo Features:

• *960 HP Capable
• Twin hydrodynamic journal bearings
• Extended tip technology compressor wheel
• Twin scroll turbine housing
• Adjustable compressor and turbine housing orientation
• Compressor cover re-circulation grooves
• Standard turbine inlet and outlet connections
• 80mm comp. Wheel Inducer Diameter
• 87mm?Turbine Wheel Outer Diameter
• 1.32 A/R T4 turbine housing

Check out our Turbo Accessories to get the most out of your turbo!

*Maximum HP ratings are only attainable with proper supporting modifications
